EKKO EK16A Series: 3-Wheel Electric Forklifts – 3,500 lbs Capacity

Name: EKKO EK16A Series: 3-Wheel Electric Forklifts – 3,500 lbs Capacity
Brand: EKKO
SKU: EK16A-138
Price: 22999.0 USD
Availability:  InStock

EKKO EK16A Series: 3-Wheel Electric Forklifts – 3,500 lbs Capacity

$22,999.00

Shipping calculated at checkout.

The EKKO EK16A-138 & EK16A-177 engineered for small aisles, limited spaces, and budget-conscious operations while delivering exceptional performance. Ideal for warehouses, manufacturing floors, stock rooms, and loading docks, this forklift provides reliable material handling with a 3,500 lb lifting capacity. Powered by a 24V AC electric drive system and 3.3 kW lift motor, it ensures efficient, quiet, and eco-friendly operation for indoor use on flat surfaces. The robust steel construction, solid cushion tires, and precision Zapi controller provide superior stability, maneuverability, and control in tight spaces.

Available Heights: 138" (EK16A-138) / 177" (EK16A-177)

⚡ Key Features

• 3,500 lb load capacity
• Compact 3-wheel design for tight aisles
• High lift heights: 138" (EK16A-138) / 177" (EK16A-177)
• Free lift: 34.4" (EK16A-138) / 29.5" (EK16A-177)
• Adjustable forks (7.9" – 26") for versatile pallet handling
• Tilt angles: 3°/6° (EK16A-138) / 2°/4° (EK16A-177)
• 24V AC drive motor with
3.3 kW (EK16A-138) / 2.2 kW (EK16A-177)
• Hydraulic Power Steering (HPS) for smooth maneuvering
• Zapi controller for precise operation
• Steel construction with robotic welding for durability
• Built-in charger and 24V/320Ah battery included
• Cushion tires for indoor use
• Recommended for indoor use on flat surfaces

🔧 Specifications

• Model: EK16A-138 / EK16A-177
• Load Capacity: 3,500 lbs
• Load Center: 20" (EK16A-138) / 24" (EK16A-177)
• Lift Height: 138" / 177"
• Free Lift: 34.4" / 29.5"
• Lowered Mast Height: 86.6" / 81"
• Fork Length: 42.1"
• Fork Adjustment Width: 7.9" – 26"
• Overall Length: 107.1"
• Overall Width: 42.1"
• Turning Radius: 58.9"
• Lift Speed (laden/unladen): 4.71 / 10.2 in/s
• Drive Motor: 24V AC
• Lift Motor: 3.3 kW / 2.2 kW
• Battery: 24V/320Ah
• Tires: Cushion
• Service Weight: 5020 lbs / 5200 lbs

🛡️ Warranty Information

• 3-Year Limited Parts Warranty covering defects in materials and workmanship
• Includes coverage for drive and lift motors, chassis, and electrical components
• Wearable parts (tires, forks, and hydraulic hoses) covered for 90 days
• Warranty support includes repair or replacement at authorized service centers
• Ensures long-term reliability and peace of mind for industrial operations
